Cloudron v9: huge disk I/O is this normal/safe/needed?
-
@imc67 not sure I remember why
Does this mean that if you disable matomo temporarily, the disk usage goes down a lot?Seems easy to fix now that we know the root cause
-
My two cents: as soon as #28 is correct, this should happen with every Cloudron instance that has Matomo (and OIDC enabled). I looked at one of my instances that met the criteria. One of the Matomo instances had about 300 sessions stored in MySQL. The oldest entry is from Feb 26.
So maybe #28 isn't correct, or it's something that only happens on this instance. -
Maybe because the three installs are 5-6 years old and had many many updates/upgrades etc?
can you check how many sessions per hour are being created? Run this query:
sqlSELECT HOUR(FROM_UNIXTIME(modified)) AS hour, COUNT(*) AS sessions FROM `<your_matomo_db>`.session WHERE DATE(FROM_UNIXTIME(modified)) = CURDATE() - INTERVAL 1 DAY GROUP BY hour ORDER BY hour;On my instances this shows exactly 360 per hour = 1 per 10 seconds = health check interval. If yours shows much less, the health checker behaves differently on your setup.
-
Maybe because the three installs are 5-6 years old and had many many updates/upgrades etc?
can you check how many sessions per hour are being created? Run this query:
sqlSELECT HOUR(FROM_UNIXTIME(modified)) AS hour, COUNT(*) AS sessions FROM `<your_matomo_db>`.session WHERE DATE(FROM_UNIXTIME(modified)) = CURDATE() - INTERVAL 1 DAY GROUP BY hour ORDER BY hour;On my instances this shows exactly 360 per hour = 1 per 10 seconds = health check interval. If yours shows much less, the health checker behaves differently on your setup.
@imc67 one app instance (4y old)
+------+----------+ | hour | sessions | +------+----------+ | 0 | 2 | | 2 | 1 | | 7 | 2 | | 8 | 1 | | 9 | 1 | | 13 | 3 | | 15 | 1 | | 17 | 3 | | 19 | 1 | | 20 | 3 | | 21 | 4 | | 22 | 1 | +------+----------+different app instance (7y old)
+------+----------+ | hour | sessions | +------+----------+ | 3 | 1 | | 5 | 2 | | 15 | 4 | | 18 | 2 | | 19 | 2 | | 20 | 2 | | 21 | 4 | | 22 | 2 | +------+----------+health check is every 10 sec.
Mar 07 18:00:50 - - - [07/Mar/2026:17:00:50 +0000] "GET / HTTP/1.1" 302 - "-" "Mozilla (CloudronHealth)" Mar 07 18:00:50 172.18.0.1 - - [07/Mar/2026:17:00:50 +0000] "GET / HTTP/1.1" 302 299 "-" "Mozilla (CloudronHealth)" Mar 07 18:01:00 - - - [07/Mar/2026:17:01:00 +0000] "GET / HTTP/1.1" 302 - "-" "Mozilla (CloudronHealth)" Mar 07 18:01:00 172.18.0.1 - - [07/Mar/2026:17:01:00 +0000] "GET / HTTP/1.1" 302 299 "-" "Mozilla (CloudronHealth)" Mar 07 18:01:10 - - - [07/Mar/2026:17:01:10 +0000] "GET / HTTP/1.1" 302 - "-" "Mozilla (CloudronHealth)" Mar 07 18:01:10 172.18.0.1 - - [07/Mar/2026:17:01:10 +0000] "GET / HTTP/1.1" 302 299 "-" "Mozilla (CloudronHealth)" Mar 07 18:01:20 - - - [07/Mar/2026:17:01:20 +0000] "GET / HTTP/1.1" 302 - "-" "Mozilla (CloudronHealth)" Mar 07 18:01:20 172.18.0.1 - - [07/Mar/2026:17:01:20 +0000] "GET / HTTP/1.1" 302 299 "-" "Mozilla (CloudronHealth)" Mar 07 18:01:30 - - - [07/Mar/2026:17:01:30 +0000] "GET / HTTP/1.1" 302 - "-" "Mozilla (CloudronHealth)" Mar 07 18:01:30 172.18.0.1 - - [07/Mar/2026:17:01:30 +0000] "GET / HTTP/1.1" 302 299 "-" "Mozilla (CloudronHealth)" -
We also found some huge MySQL tables from a Wordpress-app with dedicated MainWP due to incorrect retention settings, after correction and deletion the 1 minute
iotop -aoP -d 5is still:- Docker MySQL: 70 MB
- Host MySQL: 33 MB
- go-carbon: 6.7 MB
- jbd2: 9.9 MB
- Total: ~103 MB per minute
To put this in perspective:
- 103 MB/min = 6.2 GB/hour
- 6.2 GB/hour = 148 GB/day
- 148 GB/day = 4.4 TB/month
This is on a server with relatively low visitors across 10 sites. The vast majority of this write activity is caused by the issues identified above (Matomo health checker sessions, box.tasks accumulation, and app-level retention misconfigurations) — not by actual user traffic.
Note: these are cumulative iotop counters, not sustained rates. The actual average write speed shown by Cloudron's dashboard is ~2.5-4 MB/s, which still translates to 216-345 GB/day of unnecessary disk writes on a lightly loaded server.
-
There is a lot of information here, but I think it got all a bit too mixed together making it unclear what might actually case the disk I/O. For a start, upserting sessions in mysql does not mean it would sync to disk all the time, so this may or may not be related. Also it is unclear to me when and why how much disk I/O is expected and when it is an issue. So it becomes even harder to properly respond here.
Maybe we can try to separate the issues mainly first focusing on the potentially unnecessary session creation by the healtheck and that also ideally one application at a time. Maybe you can create those issues at the individual app packages to track those better, otherwise those issues easily get lost until such time we have resources to look into those.
-
N nebulon forked this topic on
-
N nebulon forked this topic on
-
I imc67 referenced this topic on
-
Thanks @nebulon for dividing the main issue "high disk I/O" and my three possible root causes into 3.
Here we can focus on Matomo, current situation on 3 different servers, each with one Matomo app:
ysql> SELECT COUNT(*), MIN(FROM_UNIXTIME(modified)), MAX(FROM_UNIXTIME(modified)) FROM session; +----------+------------------------------+------------------------------+ | COUNT(*) | MIN(FROM_UNIXTIME(modified)) | MAX(FROM_UNIXTIME(modified)) | +----------+------------------------------+------------------------------+ | 121230 | 2026-02-24 21:02:50 | 2026-03-10 21:43:20 | +----------+------------------------------+------------------------------+ 1 row in set (0.13 sec)mysql> SELECT COUNT(*), MIN(FROM_UNIXTIME(modified)), MAX(FROM_UNIXTIME(modified)) FROM session; +----------+------------------------------+------------------------------+ | COUNT(*) | MIN(FROM_UNIXTIME(modified)) | MAX(FROM_UNIXTIME(modified)) | +----------+------------------------------+------------------------------+ | 120811 | 2026-02-24 21:41:30 | 2026-03-10 21:43:10 | +----------+------------------------------+------------------------------+ 1 row in set (0.13 sec)mysql> SELECT COUNT(*), MIN(FROM_UNIXTIME(modified)), MAX(FROM_UNIXTIME(modified)) FROM session; +----------+------------------------------+------------------------------+ | COUNT(*) | MIN(FROM_UNIXTIME(modified)) | MAX(FROM_UNIXTIME(modified)) | +----------+------------------------------+------------------------------+ | 22494 | 2026-03-08 07:31:01 | 2026-03-10 21:40:00 | +----------+------------------------------+------------------------------+ 1 row in set (0.02 sec)This looks like a serious amount of sessions in a short time, to be exactly:
120.811 / 20.161,67 = 5,99 sessions per minuteis every 10 seconds health check.The only thing I can find in the config.ini.php regarding sessions is:
session_save_handler = ""and I don't remember me changing that? -
Here is a more complete analysis of the disk I/O across all 3 servers.
1. Cloudron Disk I/O graph (server 1, last 6 hours)
The graph shows a constant write baseline of ~2.5 MB/s, 24/7. The spike around 20:00 is the scheduled daily backup — completely normal. The total write of 646 GB over 2 days (~323 GB/day) is almost entirely this constant baseline, not user traffic or backups.
2. iotop breakdown (server 1, 1 minute measurement)
Docker MySQL (messageb): 48.62 MB/min (~0.81 MB/s) Host MySQL: 23.26 MB/min (~0.39 MB/s) go-carbon: 9.34 MB/min (~0.16 MB/s) jbd2 (fs journal): 8.44 MB/min (~0.14 MB/s) systemd-journald: 4.37 MB/min (~0.07 MB/s) containerd: 2.02 MB/min (~0.03 MB/s) dockerd: 1.13 MB/min (~0.02 MB/s) Total: ~97 MB/min (~1.6 MB/s average)Note: the average of ~1.6 MB/s is consistent with the graph baseline of ~2.5 MB/s when accounting for peaks and the fact that iotop measures a 1-minute window.
3. InnoDB write activity since last MySQL restart (all 3 servers)
Server 1 (uptime 59 min) Server 2 (uptime ~40h) Server 3 (uptime ~40h) Data written 2.13 GB 55.3 GB 63.5 GB Effective write rate ~0.58 MB/s ~0.38 MB/s ~0.43 MB/s Rows inserted/s 6.5 8.8 8.6 Rows updated/s 7.0 4.5 4.0 Log writes/s 28.7 23.6 18.0 All three servers show a consistent insert rate of ~6-9 rows/second in the Docker MySQL, matching exactly 1 new Matomo session every 10 seconds (= health check interval).
Conclusion
The Docker MySQL (~0.4-0.8 MB/s) is the largest single contributor, driven primarily by Matomo session inserts. The total observed disk I/O of 2-4 MB/s is the sum of multiple processes, with the constant Matomo session accumulation as the most significant and most easily fixable component.
-
J joseph forked this topic on
-
Summary of extensive disk I/O investigation — findings and conclusions
After spending considerable time investigating the high disk I/O on my servers (with help from an Claude PRO AI assistant, especially for this issue I subscribed to PRO!), I want to share my findings for anyone else experiencing this issue.
Setup: 3 servers running Cloudron v9.1.3, Ubuntu 22.04. Server 1 (just to focus on one): 12 WordPress sites, Matomo, EspoCRM, FreeScout (2x), Roundcube, MiroTalk, Taiga, MainWP, Yourls, Surfer (2x). Constant write I/O of ~2.5 MB/s = ~347 GB/day.
Reference: Cloudron demo server (20 apps including Nextcloud, Matrix, Discourse) shows ~80 GB/day. My servers run 4-5x higher with lighter apps.
What we investigated and measured
iotopanalysis: Docker MySQL (messageb) and host MySQL are by far the largest writers- MySQL general log analysis: mapped write distribution per table
- Tested
innodb_flush_log_at_trx_commit = 2: changes the pattern (bursts instead of constant pressure) but total write volume unchanged - Analyzed nginx access logs for suspicious traffic patterns
- Compared against Cloudron demo server
What was cleaned up (almost no impact)
- EspoCRM: deleted 244K jobs + 244K scheduled_job_log_records; set
cleanupJobPeriodto 7 days - WordPress actionscheduler_claims: deleted 130K rows
- Roundcube: reduced from 5 to 1 installation
- Matomo: adjusted
session_gc_probabilityandlogin_cookie_expire; cleared accumulated sessions - Wordfence: reduced live traffic table to 200 rows / 1 day, disabled audit logging
- MainWP: disabled uptime monitor addon and SSL monitor addon
- MainWP wp_mainwp_wp_logs: deleted 46,903 rows older than 30 days
- MainWP wp_mainwp_wp_logs_meta: deleted 141,682 orphaned records
- MainWP: disabled Network Activity logging
What was ruled out as significant I/O cause
- Matomo: stopped the app entirely → no measurable difference in I/O
- MainWP: one of the three servers has no MainWP but shows identical I/O pattern
- FreeScout: job tables are empty
- External scan traffic: all returning 404/301 from nginx, no database impact
What is proven but not fixable without Cloudron
- Matomo healthcheck bug:
GET /triggers the LoginOIDC plugin on every health check (every 10 seconds), creating a new MySQL session each time → 8,640 new sessions per day per Matomo instance. Fix requires changing the health check endpoint fromGET /to/matomo.jsin the app package. This is a Cloudron-side fix. Reported separately in topic 15211. - InnoDB configuration:
innodb_log_file_sizeis only 48MB (causes very frequent checkpoints),innodb_flush_methodis fsync. These settings are suboptimal for a write-heavy workload but are managed by Cloudron. - go-carbon/Graphite: writes ~0.13 MB/s continuously for 814 whisper metric files — inherent to Cloudron's monitoring stack.
Conclusion
There is no single large cause. The high I/O is the sum of multiple Cloudron-internal mechanisms. Everything works correctly — no performance issues, no user impact. But for a server with relatively low user traffic, 347 GB/day of writes feels disproportionate, especially compared to the Cloudron demo server at ~80 GB/day.
Sharing this in case it helps others investigating the same issue.
-
Summary of extensive disk I/O investigation — findings and conclusions
After spending considerable time investigating the high disk I/O on my servers (with help from an Claude PRO AI assistant, especially for this issue I subscribed to PRO!), I want to share my findings for anyone else experiencing this issue.
Setup: 3 servers running Cloudron v9.1.3, Ubuntu 22.04. Server 1 (just to focus on one): 12 WordPress sites, Matomo, EspoCRM, FreeScout (2x), Roundcube, MiroTalk, Taiga, MainWP, Yourls, Surfer (2x). Constant write I/O of ~2.5 MB/s = ~347 GB/day.
Reference: Cloudron demo server (20 apps including Nextcloud, Matrix, Discourse) shows ~80 GB/day. My servers run 4-5x higher with lighter apps.
What we investigated and measured
iotopanalysis: Docker MySQL (messageb) and host MySQL are by far the largest writers- MySQL general log analysis: mapped write distribution per table
- Tested
innodb_flush_log_at_trx_commit = 2: changes the pattern (bursts instead of constant pressure) but total write volume unchanged - Analyzed nginx access logs for suspicious traffic patterns
- Compared against Cloudron demo server
What was cleaned up (almost no impact)
- EspoCRM: deleted 244K jobs + 244K scheduled_job_log_records; set
cleanupJobPeriodto 7 days - WordPress actionscheduler_claims: deleted 130K rows
- Roundcube: reduced from 5 to 1 installation
- Matomo: adjusted
session_gc_probabilityandlogin_cookie_expire; cleared accumulated sessions - Wordfence: reduced live traffic table to 200 rows / 1 day, disabled audit logging
- MainWP: disabled uptime monitor addon and SSL monitor addon
- MainWP wp_mainwp_wp_logs: deleted 46,903 rows older than 30 days
- MainWP wp_mainwp_wp_logs_meta: deleted 141,682 orphaned records
- MainWP: disabled Network Activity logging
What was ruled out as significant I/O cause
- Matomo: stopped the app entirely → no measurable difference in I/O
- MainWP: one of the three servers has no MainWP but shows identical I/O pattern
- FreeScout: job tables are empty
- External scan traffic: all returning 404/301 from nginx, no database impact
What is proven but not fixable without Cloudron
- Matomo healthcheck bug:
GET /triggers the LoginOIDC plugin on every health check (every 10 seconds), creating a new MySQL session each time → 8,640 new sessions per day per Matomo instance. Fix requires changing the health check endpoint fromGET /to/matomo.jsin the app package. This is a Cloudron-side fix. Reported separately in topic 15211. - InnoDB configuration:
innodb_log_file_sizeis only 48MB (causes very frequent checkpoints),innodb_flush_methodis fsync. These settings are suboptimal for a write-heavy workload but are managed by Cloudron. - go-carbon/Graphite: writes ~0.13 MB/s continuously for 814 whisper metric files — inherent to Cloudron's monitoring stack.
Conclusion
There is no single large cause. The high I/O is the sum of multiple Cloudron-internal mechanisms. Everything works correctly — no performance issues, no user impact. But for a server with relatively low user traffic, 347 GB/day of writes feels disproportionate, especially compared to the Cloudron demo server at ~80 GB/day.
Sharing this in case it helps others investigating the same issue.
Great investigation, thanks for putting in the time and effort.
But for a server with relatively low user traffic, 347 GB/day of writes feels disproportionate, especially compared to the Cloudron demo server at ~80 GB/day.
I actually fixed some graph bugs yesterday here and here. Is that number 347GB coming from the Cloudron graph? If so, that value is actually showing the value since the server last rebooted! It has nothing to do with the window range selected. I also noticed that if you select ranges, you will see the value decrease. This was the bug I fixed.
@imc67 also, have you compared the i/o rate against your VPS provider graphs also? I wouldn't rule out a bug in cloudron graphs (we rewrote the metric system, so maybe there are bugs).
-
Great investigation, thanks for putting in the time and effort.
But for a server with relatively low user traffic, 347 GB/day of writes feels disproportionate, especially compared to the Cloudron demo server at ~80 GB/day.
I actually fixed some graph bugs yesterday here and here. Is that number 347GB coming from the Cloudron graph? If so, that value is actually showing the value since the server last rebooted! It has nothing to do with the window range selected. I also noticed that if you select ranges, you will see the value decrease. This was the bug I fixed.
@imc67 also, have you compared the i/o rate against your VPS provider graphs also? I wouldn't rule out a bug in cloudron graphs (we rewrote the metric system, so maybe there are bugs).
-
@girish I don't know if this I related but it's the first time I tried:
cloudron-support --troubleshootand this is the result, a [FAIL] that can't be solved AND it's exactly the same on my 2 other servers....:root@xxx:~# cloudron-support --troubleshoot Vendor: netcup Product: KVM Server Linux: 5.15.0-171-generic Ubuntu: jammy 22.04 Execution environment: kvm Processor: AMD EPYC 7702P 64-Core Processor x 10 RAM: 65842976KB Disk: /dev/sda3 1.9T [OK] node version is correct [OK] IPv6 is enabled and public IPv6 address is working [OK] docker is running [OK] docker version is correct [OK] MySQL is running [OK] netplan is good [OK] DNS is resolving via systemd-resolved [OK] unbound is running [OK] nginx is running [OK] dashboard cert is valid [OK] dashboard is reachable via loopback [FAIL] Database migrations are pending. Last migration in DB: /20260217120000-mailPasswords-create-table.js. Last migration file: /package.json. Please run 'cloudron-support --apply-db-migrations' to apply the migrations. [OK] Service 'mysql' is running and healthy [OK] Service 'postgresql' is running and healthy [OK] Service 'mongodb' is running and healthy [OK] Service 'mail' is running and healthy [OK] Service 'graphite' is running and healthy [OK] Service 'sftp' is running and healthy [OK] box v9.1.3 is running [OK] Dashboard is reachable via domain name [WARN] Domain xxx.nl expiry check skipped because whois does not have this information root@xxx:~# cloudron-support --apply-db-migrations Applying pending database migrations 2026-03-12T11:27:14 ==> start: Cloudron Start media:x:500: 2026-03-12T11:27:14 ==> start: Configuring docker Synchronizing state of apparmor.service with SysV service script with /lib/systemd/systemd-sysv-install. Executing: /lib/systemd/systemd-sysv-install enable apparmor 2026-03-12T11:27:15 ==> start: Ensuring directories 2026-03-12T11:27:15 ==> start: Configuring journald 2026-03-12T11:27:15 ==> start: Setting up unbound 2026-03-12T11:27:15 ==> start: Adding systemd services Synchronizing state of unbound.service with SysV service script with /lib/systemd/systemd-sysv-install. Executing: /lib/systemd/systemd-sysv-install enable unbound Synchronizing state of cron.service with SysV service script with /lib/systemd/systemd-sysv-install. Executing: /lib/systemd/systemd-sysv-install enable cron Synchronizing state of rpcbind.service with SysV service script with /lib/systemd/systemd-sysv-install. Executing: /lib/systemd/systemd-sysv-install disable rpcbind 2026-03-12T11:28:39 ==> start: Configuring sudoers 2026-03-12T11:28:39 ==> start: Unconfiguring collectd Synchronizing state of collectd.service with SysV service script with /lib/systemd/systemd-sysv-install. Executing: /lib/systemd/systemd-sysv-install disable collectd 2026-03-12T11:28:40 ==> start: Configuring logrotate 2026-03-12T11:28:40 ==> start: Adding motd message for admins 2026-03-12T11:28:40 ==> start: Configuring nginx 2026-03-12T11:28:41 ==> start: Starting mysql mysqladmin: [Warning] Using a password on the command line interface can be insecure. Warning: Since password will be sent to server in plain text, use ssl connection to ensure password safety. mysql: [Warning] Using a password on the command line interface can be insecure. mysql: [Warning] Using a password on the command line interface can be insecure. 2026-03-12T11:28:41 ==> start: Migrating data [INFO] No migrations to run [INFO] Done 2026-03-12T11:28:41 ==> start: Changing ownership 2026-03-12T11:28:41 ==> start: Starting cloudron-syslog 2026-03-12T11:28:41 ==> start: Starting Cloudron 2026-03-12T11:28:43 ==> start: Almost done [OK] Database migrations applied successfully root@xxx:~# cloudron-support --troubleshoot Vendor: netcup Product: KVM Server Linux: 5.15.0-171-generic Ubuntu: jammy 22.04 Execution environment: kvm Processor: AMD EPYC 7702P 64-Core Processor x 10 RAM: 65842976KB Disk: /dev/sda3 1.9T [OK] node version is correct [OK] IPv6 is enabled and public IPv6 address is working [OK] docker is running [OK] docker version is correct [OK] MySQL is running [OK] netplan is good [OK] DNS is resolving via systemd-resolved [OK] unbound is running [OK] nginx is running [OK] dashboard cert is valid [OK] dashboard is reachable via loopback [FAIL] Database migrations are pending. Last migration in DB: /20260217120000-mailPasswords-create-table.js. Last migration file: /package.json. Please run 'cloudron-support --apply-db-migrations' to apply the migrations. [OK] Service 'mysql' is running and healthy [OK] Service 'postgresql' is running and healthy [OK] Service 'mongodb' is running and healthy [OK] Service 'mail' is running and healthy [OK] Service 'graphite' is running and healthy [OK] Service 'sftp' is running and healthy [OK] box v9.1.3 is running [OK] Dashboard is reachable via domain name [WARN] Domain xxx.nl expiry check skipped because whois does not have this information -
O what a pity
was hoping this could be a solution
