I did some digging, this is what I think is needed:
The current package uses:
- Synapse
v1.144.0(which is compatible - MAS requires v1.136.0+) - Cloudron OIDC for SSO (traditional OIDC provider approach)
- PostgreSQL as the database
- Standard Matrix authentication endpoints
What MAS Integration Requires
MAS is fundamentally different from traditional OIDC - it's not just another identity provider, but a complete replacement for Synapse's internal authentication system per MSC3861. It needs:
1. MAS Service Deployment
- MAS needs to run as a separate service (not just a config change)
- It requires its own separate PostgreSQL database
- It needs its own domain/subdomain (e.g., auth.matrix.example.com)
- Docker image: ghcr.io/element-hq/matrix-authentication-service:latest
2. MAS Configuration Requirements
- Encryption secrets and signing keys (RSA minimum)
- Connection to Synapse via shared secret
- Database configuration for its own PostgreSQL database
- HTTP listener configuration
- Email configuration for password recovery
- Policy configuration (WASM file)
3. Synapse Configuration Changes
Replace traditional OIDC with matrix_authentication_service section:
matrix_authentication_service:
enabled: true
endpoint: http://mas-internal:8080/
secret: "SharedSecretWithMAS"
4. Reverse Proxy Changes
These Matrix endpoints must be routed to MAS (not Synapse):
/_matrix/client/*/login/_matrix/client/*/logout/_matrix/client/*/refresh
5. User Migration (For Existing Deployments)
MAS includes syn2mas tool to migrate:
- Existing password hashes (bcrypt → argon2id)
- Sessions and devices
- Access tokens
- Upstream IdP mappings
